Import Multiple Files command opens the corresponding window. File format is recognized automatically by OptiChar/OptiRE. Using this option you can import many files in one simple operation. Import Multiple Files option greatly simplifies measurement data import. It is important to use Options dialog in order to set correct types of spectra, incidence angle and X- and Y-axis units.
Import column allows to deselect some spectra excluding them from Import operation. The names can be adjusted if necessary editing cells in the Measurement Name column. On the bottom all worksheets are listed and can be changed using tabs similar to Excel file, each extracted spectrum is represented in the list to the left with specification of column name, cell range and future measurement file name. OptiChar performs smart scan of Excel file layout and represents all extracted data in the Import Spectra from Excel window. This command first opens File Open dialog, where you need to select a corresponding MS Excel file with measurement data. Import Data from Excel and Import from Multiple Files Import Spectra from Excel. New Features of OptiLayer (Version 15.12).
Error analysis: Color, EFI and Integral.Specifications for conventional targets.Multi-coating design and pulse analysis.Broadband monitoring with witness chips.Monochromatic monitoring with witness chips.Varying thicknesses and optical constants.Averaged and Integrated Characteristics.
